Digident Quick
The 3D printer devices produced by Mobtakeran Mechatronics Ark Co., Ltd., due to the all-aluminum chassis and the use of appropriate rails and ball screw in the Z axis, are devices with high stability, high accuracy, and stable and permanent work, which can be upgraded and updated to newer versions with the advancement of technology. Sensors, electronic boards, and high-quality components from well-known brands have been used in the construction of these devices.
The UV light radiation in these 3D printers is improved by 90% due to the use of LCD technology and they are compatible with almost all resins whose frequency ranges from 380 to 405 nanometers. Digident Quick printers have a 6-inch LCD and the resolution of this device is 1620*2560, which means more than 4 million pixels. The dimensions of the plate of this device are 8 x 13 cm and it is suitable for wax-up print, temporaries, cast printing, customized abutment and surgical guide. This device with small dimensions and weight of about 27 kg , is completely suitable for dental offices and dental laboratories.
Specifications :
1.High resolution (more than 8 million pixels on the working screen)
2.High print speed (4 times faster than Lite model)
3. High stability in the Z axis with higher speed
4. New optical system with more light power
5.Long life with lower maintenance cost
6. Compatible with LCD, DLP and even SLA resins
7.Integrated software with automatic model supporting
| Specifications | Digident Quick |
|---|---|
| LCD resolution | 2560*1620 pixel |
| Layer Thickness | (25-100 ?m) |
| Print Volume | 81*128*170 mm |
| Print Precision | (50 ?m) |
| Print Speed | 25~45 min for each cm |
| Printer Dimension | 26*24*52 cm |
| Screen | 7 inch touch panel |
| Net Weight | 27 kg |
| Software | chitu box |
| File Input Format | STL-PNG-ZIP-OBJ |
| Power Input | 220 Vac, 50Hz |
| Connectivity method | USB-LAN-WiFi |
| capacity of print | wax:80~90 |
| temp:80~90 | |
| Ortho cast: 10 | |
| abutment:120 | |
| sergical guide:6 | |
| Z-axis resolution | less than 5 micron |
| resin tank | permanent resin tank |
| function | wax-temperories-sergical guide-night guard-abutment-UCLA-mock-up-Ortho cast-laminate- |
| guarantee and warranty | 1 year warranty and 5 years aftersales service |
